IRSM808 Series

Manufacturer: INFINEON

Catalog

IPM MODULE, MOSFET, 250V, 20A, PQFN

Part	Applications	Technology	Package / Case	Fault Protection	Features	Operating Temperature	Load Type	Interface	Current - Output / Channel	Rds On (Typ)	Supplier Device Package	Voltage - Load [Max]	Voltage - Supply [Max]	Voltage - Supply [Min]	Mounting Type
INFINEON IRSM808-204MH	AC Motors	UMOS	31-PowerVQFN	UVLO	Bootstrap Circuit	150 °C	Inductive	Logic	20 A	130 mOhm	31-PQFN (8x9)	200 V	16.5 V	13.5 V	Surface Mount
INFINEON IRSM808-105MHTR	AC Motors	UMOS	31-PowerVQFN	UVLO	Bootstrap Circuit	150 °C	Inductive	Logic	10 A	580 mOhm	31-PQFN (8x9)	400 V	16.5 V	13.5 V	Surface Mount
INFINEON IRSM808-204MHTR	AC Motors	UMOS	31-PowerVQFN	UVLO	Bootstrap Circuit	150 °C	Inductive	Logic	20 A	130 mOhm	31-PQFN (8x9)	200 V	16.5 V	13.5 V	Surface Mount
