N3793 Series

Catalog

PIN HEADER, PCB HEADER, WIRE-TO-BOARD, 2.54 MM, 2 ROWS, 10 CONTACTS, THROUGH HOLE STRAIGHT

Part	Contact Type	Number of Positions	Termination	Contact Shape	Operating Temperature [Min]	Operating Temperature [Max]	Contact Length - Post	Contact Length - Post	Connector Type	Insulation Height [z]	Insulation Height [z]	Insulation Material	Contact Length - Mating [x]	Contact Length - Mating [x]	Number of Positions Loaded	Contact Finish - Post	Contact Finish - Mating	Fastening Type	Material Flammability Rating	Pitch - Mating	Pitch - Mating	Shrouding	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Style	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Material	Mounting Type	Number of Rows [custom]	Insulation Color	Overall Contact Length	Overall Contact Length	Current Rating (Amps)	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Length - Post [x]	Contact Length - Post [x]	Insulation Height	Insulation Height
3M Electronic Specialty N3793-6303RB	Male Pin	10	Solder	Square	-55 C	105 ░C	3.94 mm	0.155 "	Header	17.27 mm	0.68 in	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.24 in	6.1 mm	All	Tin	Gold	Latch Lock/Eject Hooks Long	UL94 V-0	0.1 "	2.54 mm	Shrouded - 4 Wall	0.76 Ám	30 Áin	Board to Board Cable	0.1 in	2.54 mm	Copper Alloy	Through Hole	2	Black	0.695 in	17.65 mm	1.75 A	200 µin	5.08 µm
3M Electronic Specialty N3793-5502	Male Pin	10	Solder	Square	-55 C	105 ░C			Header	8.64 mm	0.34 in	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.24 in	6.1 mm	All	Tin-Lead	Gold	Latch Lock/Eject Hooks	UL94 V-0	0.1 "	2.54 mm	Shrouded - 4 Wall	0.76 Ám	30 Áin	Board to Board Cable	0.1 in	2.54 mm	Copper Alloy	Right Angle Through Hole	2	Black			1.75 A	200 µin	5.08 µm	0.112 in	2.84 mm
3M Electronic Specialty N3793-6003RB	Male Pin	10	Solder	Square	-55 C	105 ░C	3.94 mm	0.155 "	Header	17.27 mm	0.68 in	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.24 in	6.1 mm	All	Tin	Gold	Push-Pull	UL94 V-0	0.1 "	2.54 mm	Shrouded - 4 Wall	0.76 Ám	30 Áin	Board to Board Cable	0.1 in	2.54 mm	Copper Alloy	Through Hole	2	Black	0.695 in	17.65 mm	1.75 A	200 µin	5.08 µm
3M Electronic Specialty N3793-6302RB	Male Pin	10	Solder	Square	-55 C	105 ░C			Header	17.27 mm	0.68 in	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.24 in	6.1 mm	All	Tin	Gold	Latch Lock/Eject Hooks Long	UL94 V-0	0.1 "	2.54 mm	Shrouded - 4 Wall	0.76 Ám	30 Áin	Board to Board Cable	0.1 in	2.54 mm	Copper Alloy	Through Hole	2	Black	0.652 in	16.56 mm	1.75 A	200 µin	5.08 µm	0.112 in	2.84 mm
3M Electronic Specialty N3793-5302RB	Male Pin	10	Solder	Square	-55 C	105 ░C			Header	8.64 mm	0.34 in	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.24 in	6.1 mm	All	Tin	Gold	Latch Lock/Eject Hooks Long	UL94 V-0	0.1 "	2.54 mm	Shrouded - 4 Wall	0.76 Ám	30 Áin	Board to Board Cable	0.1 in	2.54 mm	Copper Alloy	Right Angle Through Hole	2	Black			1.75 A	200 µin	5.08 µm	0.112 in	2.84 mm
3M Electronic Specialty N3793-6202RB	Male Pin	10	Solder	Square	-55 C	105 ░C			Header	17.27 mm	0.68 in	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.24 in	6.1 mm	All	Tin	Gold	Latch Lock/Eject Hooks	UL94 V-0	0.1 "	2.54 mm	Shrouded - 4 Wall	0.76 Ám	30 Áin	Board to Board Cable	0.1 in	2.54 mm	Copper Alloy	Through Hole	2	Black	0.652 in	16.56 mm	1.75 A	200 µin	5.08 µm	0.112 in	2.84 mm
3M Electronic Specialty N3793-1002RB	Male Pin	10	Solder	Square	-55 C	105 ░C			Header			Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.24 in	6.1 mm	All	Tin	Gold	Push-Pull	UL94 V-0	0.1 "	2.54 mm	Shrouded - 3 Wall	0.76 Ám	30 Áin	Board to Board Cable	0.1 in	2.54 mm	Copper Alloy	Right Angle Through Hole	2	Black			1.75 A	200 µin	5.08 µm	0.112 in	2.84 mm	7.87 mm	0.31 in
3M Electronic Specialty N3793-D302RB	Male Pin		Solder	Square	-55 C	105 ░C			Header Stackable (2)			Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.24 in	6.1 mm	All	Tin	Gold	Latch Lock/Eject Hooks Long	UL94 V-0	0.1 "	2.54 mm	Shrouded - 3 Wall	0.76 Ám	30 Áin	Board to Board Cable	0.1 in	2.54 mm	Copper Alloy	Right Angle Through Hole	2	Black				200 µin	5.08 µm	0.112 in	2.84 mm	16.76 mm	0.66 in
3M Electronic Specialty N3793-2302RB	Male Pin	10	Solder	Square	-55 C	105 ░C			Header	17.27 mm	0.68 in	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.24 in	6.1 mm	All	Tin	Gold	Latch Lock/Eject Hooks Long	UL94 V-0	0.1 "	2.54 mm	Shrouded - 3 Wall	0.76 Ám	30 Áin	Board to Board Cable	0.1 in	2.54 mm	Copper Alloy	Through Hole	2	Black	0.652 in	16.56 mm	1.75 A	200 µin	5.08 µm	0.112 in	2.84 mm
3M Electronic Specialty N3793-1202RB	Male Pin	10	Solder	Square	-55 C	105 ░C			Header			Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.24 in	6.1 mm	All	Tin	Gold	Latch Lock/Eject Hooks	UL94 V-0	0.1 "	2.54 mm	Shrouded - 3 Wall	0.76 Ám	30 Áin	Board to Board Cable	0.1 in	2.54 mm	Copper Alloy	Right Angle Through Hole	2	Black			1.75 A	200 µin	5.08 µm	0.112 in	2.84 mm	7.87 mm	0.31 in
