293654-3
ActiveTE Connectivity Raychem Cable Protection
NECTOR S-LINE PCB ASSY 90DEG. REC.
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 293654-3 |
|---|---|
| Connector Type | Female Sockets, Plug |
| Contact Finish | Tin |
| Contact Material | Copper Alloy |
| Current Rating (Amps) | 6 A |
| Features | Keying HV-4, Board Lock |
| Housing Color | White |
| Housing Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Mounting Type | Through Hole, Right Angle |
| Number of Positions | 2 |
| Operating Temperature [Max] | 120 °C |
| Operating Temperature [Min] | -40 °C |
| Pitch [x] | 0.146 in |
| Pitch [x] | 3.7 mm |
| Style | Board to Cable/Wire |
| Termination | Solder |
| Voltage Rating | 125 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 3.72 | |
| 10 | $ 2.58 | |||
| 100 | $ 2.32 | |||
Description
General part information
NECTOR S Series
Cable-to-Board, 2 Position, Printed Circuit Board, Plug, Connector Assembly, 125 VAC, Power, Board Mount, NECTOR S, Plug & Socket Lighting Connectors
