Connectors, Interconnects
2316315-2
ActiveTE Connectivity Raychem Cable Protection
HEAVY DUTY POWER CONNECTORS HMN-HD1-24-M
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 2316315-2 |
|---|---|
| Connector Type | Module without Contacts |
| Current Rating (Amps) | 3.7 A |
| Gender | Male |
| Housing Material | Polybutylene Terephthalate (PBT) |
| Material Flammability Rating | UL94 V-0 |
| Number of Positions | 24 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Termination Style | Crimp |
| Voltage Rating | 300 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
T2111322101 Series
Automotive Connectors HMN-008-F HEAVYDUTY RECT SIBAS
