Connectors, Interconnects
1546927-5
ActiveTE Connectivity Raychem Cable Protection
CONN BARRIER STRIP 5 POS 8.26MM SOLDER RA THRU-HOLE 15A/CONTACT PACKAGE
Deep-Dive with AI
Search across all available documentation for this part.
Connectors, Interconnects
1546927-5
ActiveTE Connectivity Raychem Cable Protection
CONN BARRIER STRIP 5 POS 8.26MM SOLDER RA THRU-HOLE 15A/CONTACT PACKAGE
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 1546927-5 |
|---|---|
| Barrier Type | 3 Wall (Tri) |
| Bottom Termination | PC Pin |
| Color | Black |
| Current Rating (Amps) | 15 A |
| Features | Cover |
| Material - Insulation | Polybutylene Terephthalate (PBT) |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Circuits | 5 |
| Number of Rows | 1 |
| Number of Wire Entries | 5 |
| Operating Temperature [Max] | 120 °C |
| Operating Temperature [Min] | -40 °C |
| Pitch [x] | 8.26 mm |
| Pitch [x] | 0.325 in |
| Terminal Block Type | Barrier Block |
| Terminal Screw Finish | Nickel |
| Terminal Screw Material | Steel |
| Top Termination | Screws with Captive Plate |
| Voltage Rating | 300 VDC |
| Wire Gauge [Max] | 22 AWG |
| Wire Gauge [Min] | 14 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
BUCHANAN 4 Series Series
5 Position Barrier Strip, Tri-Barrier, Printed Circuit Pin Bottom Termination, Wire-to-Board, 8.26 mm [.325 in] Centerline, 1 Row, BUCHANAN 4 Series
