Technical Specifications
Parameters and characteristics for this part
| Specification | 1-171197-0 |
|---|---|
| Color | Natural |
| Connector Type | Plug |
| Contact Termination | Crimp |
| Contact Type | Female Socket |
| Fastening Type | Latch Lock |
| Insulation Material | Polyamide (PA), Nylon |
| Mounting Type | Panel Mount, Snap-In |
| Number of Positions | 9 |
| Number of Rows | 3 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | 0 °C |
| Pitch [x] | 0.201 in |
| Pitch [x] | 5.1 mm |
| Row Spacing | 0.24 in |
| Row Spacing | 6.1 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 1.39 | |
| 10 | $ 1.30 | |||
| 25 | $ 1.25 | |||
| 50 | $ 1.24 | |||
| 100 | $ 1.12 | |||
| 250 | $ 1.08 | |||
| 500 | $ 0.99 | |||
| 1000 | $ 0.88 | |||
| 2500 | $ 0.82 | |||
Description
General part information
Commercial MATE-N-LOK Series
9 Position, Plug, Housing, Crimp, Wire-to-Panel / Wire-to-Wire, UL 94V-2, 5.1 mm [.202 in] Centerline, 3 Row, 250 VAC, Commercial MATE-N-LOK
