VK06 Series

Catalog

TERM BLOCK HDR 6POS 45DEG 5.08MM

Part	Contact Tail Length	Contact Tail Length	Color	Housing Material	Contact Mating Finish	Voltage - UL	Header Orientation	Number of Levels	Termination Style	Material Flammability Rating	Insulation Height	Insulation Height	Mounting Type	Type	Positions Per Level	Contact Material	Number of Positions	Operating Temperature [Min]	Operating Temperature [Max]	Pitch [x]	Pitch [x]	Current - UL	Features
Amphenol Anytek VK0651500000G	0.161 in	4.1 mm	Green	Thermoplastic Resin	Tin	300 V	45 °	1	Solder	UL94 V-0	14.5 mm	0.571 in	Through Hole	Header Male Pins Shrouded (4 Side)	6	Copper Alloy	6	-40 °C	115 °C	0.2 in	5.08 mm
Amphenol Anytek VK0632500000G	0.134 in	3.4 mm	Green	Thermoplastic Resin	Tin	300 V	45 °	1	Solder	UL94 V-0	11 mm	0.433 in	Through Hole	Header Male Pins Shrouded (4 Side)	6	Copper Alloy	6	-40 °C	115 °C	0.15 in	3.81 mm	8 A	Mating Flange
Amphenol Anytek VK0611500000G	0.134 in	3.4 mm	Green	Thermoplastic	Tin	300 V	45 °	1	Solder	UL94 V-0	11 mm	0.433 in	Through Hole	Header Male Pins Shrouded (4 Side)	6	Copper	6	-40 °C	115 °C	0.138 in	3.5 mm	8 A
Amphenol Anytek VK0612500000G	0.134 in	3.4 mm	Green	Thermoplastic	Tin	300 V	45 °	1	Solder	UL94 V-0	11 mm	0.433 in	Through Hole	Header Male Pins Shrouded (4 Side)	6	Copper	6	-40 °C	115 °C	0.138 in	3.5 mm	8 A	Mating Flange
Amphenol Anytek VK0631500000G	0.134 in	3.4 mm	Green	Thermoplastic Resin	Tin	300 V	45 °	1	Solder	UL94 V-0	11 mm	0.433 in	Through Hole	Header Male Pins Shrouded (4 Side)	6	Copper Alloy	6	-40 °C	115 °C	0.15 in	3.81 mm	8 A
Amphenol Anytek VK0650500000G	0.161 in	4.1 mm	Green	Thermoplastic	Tin	300 V	45 °	1	Solder	UL94 V-0	14.5 mm	0.571 in	Through Hole	Header Male Pins Shrouded (2 Side)	6	Copper	6	-40 °C	115 °C	0.2 in	5.08 mm
Amphenol Anytek VK0672500000G	0.161 in	4.1 mm	Green	Thermoplastic Resin	Tin	300 V	45 °	1	Solder	UL94 V-0	14.5 mm	0.571 in	Through Hole	Header Male Pins Shrouded (4 Side)	6	Copper Alloy	6	-40 °C	115 °C	0.197 in	5 mm		Mating Flange
Amphenol Anytek VK0670500000G	0.161 in	4.1 mm	Green	Thermoplastic	Tin	300 V	45 °	1	Solder	UL94 V-0	14.5 mm	0.571 in	Through Hole	Header Male Pins Shrouded (2 Side)	6	Copper	6	-40 °C	115 °C	0.197 in	5 mm
Amphenol Anytek VK0671500000G	0.161 in	4.1 mm	Green	Thermoplastic Resin	Tin	300 V	45 °	1	Solder	UL94 V-0	14.5 mm	0.571 in	Through Hole	Header Male Pins Shrouded (4 Side)	6	Copper Alloy	6	-40 °C	115 °C	0.197 in	5 mm
