VK03 Series

Catalog

TERM BLOCK HDR 3POS 45DEG 5MM

Part	Header Orientation	Contact Mating Finish	Positions Per Level	Insulation Height	Insulation Height	Type	Material Flammability Rating	Contact Material	Color	Mounting Type	Housing Material	Termination Style	Operating Temperature [Min]	Operating Temperature [Max]	Number of Levels	Voltage - UL	Pitch [x]	Pitch [x]	Contact Tail Length	Contact Tail Length	Features	Current - UL
Amphenol Anytek VK0371500000G	45 °	Tin	3	14.5 mm	0.571 in	Header Male Pins Shrouded (4 Side)	UL94 V-0	Copper Alloy	Green	Through Hole	Thermoplastic Resin	Solder	-40 °C	115 °C	1	300 V	5 mm	0.197 in	0.161 in	4.1 mm
Amphenol Anytek VK0312500000G	45 °	Tin	3	11 mm	0.433 in	Header Male Pins Shrouded (4 Side)	UL94 V-0	Copper	Green	Through Hole	Thermoplastic	Solder	-40 °C	115 °C	1	300 V	3.5 mm	0.138 in	0.134 in	3.4 mm	Mating Flange	8 A
Amphenol Anytek VK0372500000G	45 °	Tin	3	14.5 mm	0.571 in	Header Male Pins Shrouded (4 Side)	UL94 V-0	Copper Alloy	Green	Through Hole	Thermoplastic Resin	Solder	-40 °C	115 °C	1	300 V	5 mm	0.197 in	0.161 in	4.1 mm	Mating Flange
Amphenol Anytek VK0311500000G	45 °	Tin	3	11 mm	0.433 in	Header Male Pins Shrouded (4 Side)	UL94 V-0	Copper	Green	Through Hole	Thermoplastic	Solder	-40 °C	115 °C	1	300 V	3.5 mm	0.138 in	0.134 in	3.4 mm		8 A
Amphenol Anytek VK0370500000G	45 °	Tin	3	14.5 mm	0.571 in	Header Male Pins Shrouded (2 Side)	UL94 V-0	Copper	Green	Through Hole	Thermoplastic	Solder	-40 °C	115 °C	1	300 V	5 mm	0.197 in	0.161 in	4.1 mm
Amphenol Anytek VK0332500000G	45 °	Tin	3	11 mm	0.433 in	Header Male Pins Shrouded (4 Side)	UL94 V-0	Copper Alloy	Green	Through Hole	Thermoplastic Resin	Solder	-40 °C	115 °C	1	300 V	3.81 mm	0.15 in	0.134 in	3.4 mm	Mating Flange	8 A
Amphenol Anytek VK0350500000G	45 °	Tin	3	14.5 mm	0.571 in	Header Male Pins Shrouded (2 Side)	UL94 V-0	Copper	Green	Through Hole	Thermoplastic	Solder	-40 °C	115 °C	1	300 V	5.08 mm	0.2 in	0.161 in	4.1 mm
