ALCOSWITCH AVH22 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
SWITCH PUSHBUTTON SPDT 26A 125V
| Part | Electrical Life | Mechanical Life | Current Rating (Amps) | Voltage Rating - AC | Illumination Voltage (Nominal) | Color - Actuator/Cap | Mounting Type | Actuator Type | Panel Cutout Dimensions [diameter] | Illumination Type, Color | Circuit | Actuator Marking | Operating Temperature [Max] | Operating Temperature [Min] | Termination Style | Type | Ingress Protection | Switch Function |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 10000 Cycles | 500000 Cycles | 26 A | 125 V | 24 V | Silver | Panel Mount Front | Button Flush Round | 22.2 mm | Blue LED | SPDT | No Marking | 85 °C | -25 °C | Quick Connect - 0.250" (6.3mm) | Anti-Vandal Illuminated | IP67 - Dust Tight Waterproof | On-On |
 TE Connectivity AMP Connectors | 50000 Cycles | 1000000 Cycles | 16 A | 125 V | 24 V | Silver | Panel Mount Front | Button Flush Round | 22.2 mm | LED Yellow | SPDT | No Marking | 85 °C | -25 °C | Quick Connect | Anti-Vandal Illuminated | IP67 - Dust Tight Waterproof | On-Mom |
 TE Connectivity AMP Connectors | 50000 Cycles | 1000000 Cycles | 16 A | 125 V | 24 V | Silver | Panel Mount Front | Button Flush Round | 22.2 mm | LED White | SPDT | Power Symbol | 85 °C | -25 °C | Quick Connect | Anti-Vandal Illuminated | IP67 - Dust Tight Waterproof | On-Mom |
 TE Connectivity AMP Connectors | 50000 Cycles | 1000000 Cycles | 16 A | 125 V | 12 VDC | Silver | Panel Mount Front | Button Flush Round | 22.2 mm | Blue LED Red | SPDT | No Marking | 85 °C | -25 °C | Quick Connect | Anti-Vandal Illuminated | IP67 - Dust Tight Waterproof | On-Mom |
 TE Connectivity AMP Connectors | 50000 Cycles | 500000 Cycles | 16 A | 125 V | 12 VDC | Silver | Panel Mount Front | Button Flush Round | 22.2 mm | Green/Red LED | SPDT | Power Symbol | 85 °C | -25 °C | Quick Connect | Anti-Vandal Illuminated | IP67 - Dust Tight Waterproof | On-On |
 TE Connectivity AMP Connectors | 10000 Cycles | 1000000 Cycles | 26 A | 125 V | 12 VDC | Silver | Panel Mount Front | Button Flush Round | 22.2 mm | LED White | SPDT | Power Symbol | 85 °C | -25 °C | Quick Connect - 0.250" (6.3mm) | Anti-Vandal Illuminated | IP67 - Dust Tight Waterproof | On-Mom |
 TE Connectivity AMP Connectors | 10000 Cycles | 1000000 Cycles | 26 A | 125 V | 24 V | Silver | Panel Mount Front | Button Flush Round | 22.2 mm | LED Red | SPDT | Power Symbol | 85 °C | -25 °C | Quick Connect - 0.250" (6.3mm) | Anti-Vandal Illuminated | IP67 - Dust Tight Waterproof | On-Mom |
 TE Connectivity AMP Connectors | 10000 Cycles | 500000 Cycles | 26 A | 125 V | 12 VDC | Silver | Panel Mount Front | Button Flush Round | 22.2 mm | Blue LED | SPDT | Power Symbol | 85 °C | -25 °C | Quick Connect - 0.250" (6.3mm) | Anti-Vandal Illuminated | IP67 - Dust Tight Waterproof | On-On |
TE Connectivity AMP Connectors | 50000 Cycles | 500000 Cycles | 16 A | 125 V | 24 V | Silver | Panel Mount Front | Button Flush Round | 22.2 mm | Blue LED Red | SPDT | Power Symbol | 85 °C | -25 °C | Quick Connect | Anti-Vandal Illuminated | IP67 - Dust Tight Waterproof | On-On |
TE Connectivity AMP Connectors | 10000 Cycles | 1000000 Cycles | 26 A | 125 V | 12 VDC | Silver | Panel Mount Front | Button Flush Round | 22.2 mm | Green/Red LED | SPDT | No Marking | 85 °C | -25 °C | Quick Connect - 0.250" (6.3mm) | Anti-Vandal Illuminated | IP67 - Dust Tight Waterproof | On-Mom |
