SQR2260 Series
Manufacturer: SQUARE D BY SCHNEIDER ELECTRIC
Catalog
SWITCH ROCKER SP3T 15A 120V
| Part | Termination Style | Circuit | Color - Actuator/Cap | Actuator Marking | Voltage Rating - AC | Current Rating (Amps) | Actuator Type | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] |
|---|---|---|---|---|---|---|---|---|---|---|
 SQUARE D BY SCHNEIDER ELECTRIC | Screw Terminal | SP3T | White | No Marking | 120 V | 15 A | Flat | Flange Panel Mount | 40 °C | 0 °C |
 SQUARE D BY SCHNEIDER ELECTRIC | Screw Terminal | SP3T | Black | No Marking | 120 V | 15 A | Flat | Flange Panel Mount | 40 °C | 0 °C |
 SQUARE D BY SCHNEIDER ELECTRIC | Screw Terminal | SP3T | Almond | No Marking | 120 V | 15 A | Flat | Flange Panel Mount | 40 °C | 0 °C |
 SQUARE D BY SCHNEIDER ELECTRIC | Screw Terminal | SP3T | White | No Marking | 120 V | 15 A | Flat | Flange Panel Mount | 40 °C | 0 °C |
 SQUARE D BY SCHNEIDER ELECTRIC | Screw Terminal | SP3T | Black | No Marking | 120 V | 5 A | Flat | Flange Panel Mount | 40 °C | 0 °C |
 SQUARE D BY SCHNEIDER ELECTRIC | Screw Terminal | SP3T | No Marking | 120 V | 15 A | Flat | Flange Panel Mount | 40 °C | 0 °C |
