Cables, Wires - Management

SRFR-10/6.5-8-SP

Active

TE Connectivity Aerospace, Defense and Marine

HEATSHRINK 0.394" GRAY METER

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

Cables, Wires - Management

SRFR-10/6.5-8-SP

Active

TE Connectivity Aerospace, Defense and Marine

HEATSHRINK 0.394" GRAY METER

Deep-Dive with AI

DocumentsDatasheet

Specifications Series Pricing Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	SRFR-10/6.5-8-SP

Color	Gray
Features	Flame Retardant
Inner Diameter - Recovered [diameter]	0.256 in
Inner Diameter - Recovered [diameter]	6.5 mm
Inner Diameter - Supplied [diameter]	0.394 in
Inner Diameter - Supplied [diameter]	10.01 mm
Length	Enter Number of Meters in Order Quantity
Length [x]	1 m, 5 m
Length [x]	3.28 ft, 16.4 ft
Material	Silicone Rubber
Operating Temperature [Max]	200 °C
Operating Temperature [Min]	-103 °F
Recovered Wall Thickness	1.5 mm
Recovered Wall Thickness	0.059 in
Shrink Temperature	135 C
Shrinkage Ratio [Max]	1.75
Shrinkage Ratio [Min]	1
Spool Size	98.4 ft
Spool Size	30 m
Type	Tubing, Flexible

SRFR Series

Part	Material	Operating Temperature [Max]	Operating Temperature [Min]	Color	Length	Length	Length	Shrinkage Ratio [Max]	Shrinkage Ratio [Min]	Length [x]	Length [x]	Inner Diameter - Recovered	Inner Diameter - Recovered	Type	Inner Diameter - Supplied [diameter]	Inner Diameter - Supplied [diameter]	Shrink Temperature	Recovered Wall Thickness	Recovered Wall Thickness	Inner Diameter - Recovered [diameter]	Inner Diameter - Recovered [diameter]	Features	Spool Size	Spool Size	Recovered Wall Thickness
TE Connectivity Aerospace, Defense and Marine SRFR-4/2.9-8-SP	Silicone Rubber	200 °C	-103 °F	Gray	25 m 50 m	82 ft 164 ft	Enter Number of Meters in Order Quantity	1.38	1	3.28 ft 16.4 ft	1 m 5 m	0.114 in	2.9 mm	Tubing Flexible	0.158 in	4.01 mm	135 C	0.99 mm	0.039 in
TE Connectivity Aerospace, Defense and Marine SRFR-2.9/1.7-8-SP	Silicone Rubber	200 °C	-103 °F	Gray	25 m	82 ft	Enter Number of Meters in Order Quantity	1.75	1	16.4 ft	5 m			Tubing Flexible	0.114 in	2.9 mm	135 C	0.99 mm	0.039 in	0.066 "	1.68 mm	Flame Retardant
TE Connectivity Aerospace, Defense and Marine SRFR-10/6.5-8-SP	Silicone Rubber	200 °C	-103 °F	Gray			Enter Number of Meters in Order Quantity	1.75	1	3.28 ft 16.4 ft	1 m 5 m			Tubing Flexible	0.394 in	10.01 mm	135 C	1.5 mm	0.059 in	0.256 in	6.5 mm	Flame Retardant	98.4 ft	30 m
TE Connectivity Aerospace, Defense and Marine SRFR-41/27-8-SP	Elastomer	200 °C	-103 °F	Gray				1.75	1					Tubing Flexible	1.614 in	41 mm	135 C	3 mm	0.118 in	1.063 in	27 mm	Flame Retardant
TE Connectivity Aerospace, Defense and Marine SRFR-21/13-8-SP	Silicone Rubber	200 °C	-103 °F	Gray				1.75	1			0.512 in	13 mm	Tubing Flexible	0.827 in	21.01 mm	135 C	0.079 in				Flame Retardant			2.01 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 523.29
		1	$ 119.72
	Digi-Spool®, Continuous Spool	1	$ 151.67
		2	$ 128.37
		3	$ 122.23
		5	$ 142.19
		10	$ 132.71
		25	$ 126.07
		50	$ 123.23

Description

General part information

SRFR Series

Heat Shrink Tubing, Flexible 0.394" (10.01mm) 1.75 to 1 Gray Enter Number of Meters in Order Quantity
